Conical Twin Screw Extruder

Products

Conical Twin Screw Extruder

  • Details

Description

JKS Conical Twin Screw Extruder are used in conjunction with different downstream equipment for the production of complete lines of SPC flooring, WPC foam boards, PVC imitation marble sheet, PVC wall panels, PVC profiles, WPC profiles, PVC pipes and PVC granules.JKS Conical Twin Screw Extruder are equipped with the well-known gearboxes, screws and barrels, ABB inverters, contactors and motors.JKS Conical Twin Screw Extruder is based on the use of two conical screws rotating in opposite directions in the barrel. The advantages of Conical Twin Screw Extruder compared to single-screw extruders are higher output and better plasticization of plastics.JKS Conical Twin Screw Extruder are only the extruders in PVC sheet extruders, if you need the whole extrusion line, please contact us.JKS Conical Twin Screw Extruder can also be used in plastic sheet extrusion lines. If you buy our machine, we will provide you with training on the operation of the machine, we will inform you about the temperature of different raw materials, and we can also provide you with troubleshooting guides for the extrusion process.

Parameters

Model SJSZ51 SJSZ55 SJSZ65 SJSZ80 SJSZ92 SJSZ110
Screw Diameter (mm) 51/105 55/110 65/132 80/156 92/188 110/220
Screw Rotation Speed (rmp) 3-32 3-34 3.5-34.4 3.57-37 1-32.9 3-32
Main Motor Power(kw) 18.5 22 37 55 90 200
Capacity (kg/h) 120 150 250 400 500-600 1000

Equipments
